Nominal Size (mm)

DN50~DN6000

DN50~DN6000

Average Flow Velocity (m/s)

0.05~10

0.02~0.5

0.5~10

Accuracy Class

1

1

0.5

Measuring Tube (Primary Element)

Working Temperature

-20℃~+150℃

Relative Humidity

95%

Protection

IP68 (Probe, Junction Box)

Pipe Material

Carbon Steel, Stainless Steel, Others

Material

PE, Stainless Steel, Titanium Alloy

Controller (Secondary Instrument)

Explosion-proof Grade

Ex d b Il C T6 Gb

Flow Units

m³, L, Gallon

Output Signal

4-20mA, Pulse, RS232C, RS485, Alarm

Display Parameters

Instantaneous Flow, Accumulated Flow, Time, Speed, Sound Speed

Ambient Temperature

-40℃~+60℃

Protection

IP 67

Power Supply

110 (60Hz) / 220 (50Hz) VAC, 24VDC (optional)

Power Consumption

15W

Dimensions

285x217x155 mm (LxWxH)

Cable Hole Specification

Cable Lock PG11, Main Cable Lock PG21

Signal Cable (2-core Ф8mm, 4-core 10mm)
